معرفی ذخیره ساز HPE D8000 Disk Enclosure
آیا شما در مجموعه خود نیاز به یک ذخیره ساز (DAS) مقرون به صرفه و متراکم با سرعت انتقال 12Gb/s دارید؟
Hewlett Packard Enterprise ذخیره ساز HPE D8000 را برای سرورهای ProLiant بگونه ای توسعه داده که این دستگاه ترکیبی از سادگی ومقرون به صرفه بودن را بدون کاهش کارایی و انعطاف پذیری ارائه می دهد.HPE D8000 Disk Enclosure با توجه به ویژگی هایش ( مقرون بصرفه و متراکم بودن ) برای محیط هایی طراحی شده که مقدار داده در آن بصورت فشرده می باشد.این Enclosure علاوه بر اینکه بعنوان direct-attached storage یا DAS استفاده می شود کاربرد هایی در زمینه محافظت از داده، پشتیبان گیری ابری و محیط های داده بزرگ(Big Data) دارد.
D8000 Disk Enclosure به وسیله کنترلر های HPE Smart Array E208e-p SR Gen10 و HPE Smart Array P408e-p SR Gen10 می تواند به سرور های ProLiant Gen10 متصل شود که شامل HPE Apollo و HPE StoreEasyنیز می شود. با اتصال دو D8000 enclosure می توانیم از 212 درایو پشتیبانی کنیم.
ویژگی های دستگاه :
پپشتیبانی از RAID های :
- RAID 0 (striping) provides no extra data protection.
- RAID 1 (mirroring) protects against failure of one drive.
- RAID 1+0 (mirroring and striping) protects against failure of one drive (and failure of particular multiple drives).
- RAID 5 (distributed data guarding) protects against failure of one drive.
- RAID 6 with ADG (Advanced Data Guarding): This is the highest level of fault tolerance.
- RAID 50 (RAID 5+0) protects against failure of one drive (and failure of particular multiple drives).
- RAID 60 (RAID 6+0) allows administrators to split the RAID 6 storage across multiple external boxes.
- RAID 1 ADM (Advanced Data Mirroring) allows customers to create mirrored RAID set using 3 identical hard drives.
پشتیانی از کنترلر های HPE Smart Array :
HPE Smart Array E208e-p SR Gen10 Controller
- Storage interface (SAS/SATA)
- 8 SAS lanes across 2 x4 external Mini-SAS HD ports
- 12Gb/s SAS, 6Gb/s SATA technology
- Support for SAS tape drives
- PCI Express 3.0 x8 link
- RAID 0, 1, 5, 10
- Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
- Legacy and UEFI boot operation
- UEFI System Utilities (storage configuration)
- Up to 238 physical drives
- Up to 64 logical drives
- HPE Smart Array SR Secure Encryption (optional license)
- HPE SSD Smart Path
- Rapid Parity Initialization (RPI)
- Rapid rebuild
- Drive Sanitize
- Performance Optimization-Degraded Reads and Read Coalescing
- Power efficiency
- Seamless upgrades from HPE Smart Array Software RAID
- Seamless upgrades to HPE Smart Array P-class Controllers
HPE Smart Array P408e-p SR Gen10 Controller
- Storage interface (SAS/SATA)
- 8 SAS lanes across 2 x4 external Mini-SAS HD ports
- 12Gb/s SAS, 6Gb/s SATA technology
- Support for SAS tape drives, SAS tape autoloaders and SAS tape libraries
- 4 GB Flash-Backed Write Cache (FBWC)
- PCI Express 3.0 x8 link
- RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM (Advanced Data Mirroring)
- Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
- Legacy and UEFI boot operation
- UEFI System Utilities (storage configuration)
- Up to 238 physical drives
- Up to 64 logical drives
- HPE Smart Array SR SmartCache (optional license)
- HPE Smart Array SR Secure Encryption (optional license)
- HPE SSD Smart Path
- Rapid Parity Initialization (RPI)
- Rapid rebuild
- Drive Sanitize
- Performance Optimization-Degraded Reads and Read Coalescing
- Power efficiency
- Seamless upgrades from HPE Smart Array S-class and E-class controllers
- FIPS 140-2 Level 1 Implementation Under Test (expected validation complete in 2018)
پپشتیبانی از درایو های :
12G 3.5″ SAS Midline (MDL) Hard Disk Drives
HPE 18TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P37669-K21
HPE 16TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P23608-K21
HPE 14TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P09155-K21
HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD 881781-K21
HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P09149-K21
HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD 861746-K21
6G 3.5″ SATA Hard Disk Drives
HPE 18TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P37678-K21
HPE 16TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P23449-K21
HPE 14TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P09165-K21
HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD 881787-K21
HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD P09161-K21
HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD 834028-K21
HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD 861742-K21
12G 3.5″ SAS Solid State Drives (SSD) in Converter carriers
HPE 960GB SAS 12G Mixed Use LFF LPC Value SAS Multi Vendor SSD P37009-K21
